Maytag Washer Not Spinning: Causes, Diagnosis, and Fixes

When your Maytag washer fills with water and agitates but won't spin — or won't do either — you're left with a tub full of sopping wet clothes and no way to get the water out. Maytag washers are built to be dependable, but mechanical and electrical components eventually wear out. Whether you have a Maytag Centennial (MVWC565FW), Bravos XL (MVWB765FW), or a Maytag Commercial Technology model (MVWP575GW), this guide covers every cause of spin failure and how to fix it.

Understanding Maytag Washer Spin Systems

Maytag uses two main drive systems depending on the model:

1. Belt-driven (older models and some Centennial models): A motor drives a belt that connects to the transmission/clutch assembly. The transmission converts motor rotation into the agitation and spin motions.

2. Direct-drive (newer Bravos and Commercial Technology models): The motor connects directly to the wash basket through a shift actuator and splutch assembly. There's no belt — the motor drives the basket directly.

Front-load Maytag washers (Maxima series, MHW models) use a direct-drive system with a stator and rotor mounted on the rear of the drum.

Understanding which system your model uses is important because it determines which components to check.

1. Lid Switch Assembly Failure (Top-Load Models)

Every top-load Maytag washer has a lid switch that prevents the drum from spinning when the lid is open. If this switch fails, the washer won't spin even with the lid closed because the control board thinks it's open.

Symptoms:

• Washer fills and agitates normally but doesn't spin
• No spin cycle activity at all
• No clicking sound when you close the lid

How to diagnose:

1. Close the lid and listen for a click or latch engagement.
2. On newer models with an electronic lid lock (part W10238287 or W10404050), the lid physically locks during spin. If you don't hear the lock motor activate (a small buzzing sound), the lock assembly may have failed.
3. Unplug the washer and test the lid switch for continuity when the lid actuator is engaged.

Common part numbers:

• W10238287 — Lid lock assembly for Centennial and Bravos models
• W10404050 — Updated lid lock for newer Centennial models
• WP3949238 — Lid switch for older belt-driven models

Cost: $25–$60 for the part. Professional repair runs $150–$250.

2. Shift Actuator Failure

The shift actuator is a motorized component on direct-drive Maytag washers that switches the transmission between agitate and spin modes. It's one of the most common failure points on Centennial and Bravos models.

Symptoms:

• Washer agitates but won't transition to spin
• You hear a humming or buzzing sound when spin should start
• Error code F7 E1 or F7 E5 on models with a display
• The washer completes the cycle but clothes are still soaking wet

How it works: The shift actuator (part W10913953 or W10597177) rotates a cam that engages either the agitate or spin mechanism in the transmission. When the actuator motor wears out, it can't complete the shift to spin mode.

How to diagnose:

1. Unplug the washer and tilt it back against the wall (carefully).
2. The shift actuator is mounted on the rear of the gearcase at the bottom of the washer.
3. Disconnect the electrical connector and test the motor coil for resistance: it should read approximately 3,000–5,000 ohms. Open circuit or significantly different resistance indicates failure.
4. You can also run a diagnostic cycle: with the washer in standby, rotate the cycle selector knob counterclockwise one click, then clockwise three clicks, counterclockwise one click, clockwise one click. The washer enters test mode and will attempt a spin cycle.

Cost: $40–$70 for the part. Professional repair runs $180–$280 total.

3. Worn Drive Belt

On belt-driven Maytag models, a rubber belt connects the motor to the transmission. Over time, the belt stretches, cracks, or breaks entirely.

Symptoms:

• Motor runs (you can hear it humming) but the drum doesn't spin or agitate
• Burning rubber smell during operation
• Black rubber residue inside the cabinet
• Weak or inconsistent spin speed

How to check:

1. Unplug the washer.
2. Tilt the washer back or remove the cabinet (on Centennial models, remove the two screws at the rear top and tilt the cabinet forward).
3. Inspect the belt for cracks, fraying, glazing (shiny surface), or breakage.
4. A properly tensioned belt should deflect about 1/2 inch when pressed in the middle of its longest span.

Part numbers:

• WP21352320 — Most Maytag/Whirlpool top-load belt-driven models
• WPW10006384 — Some Centennial models

Cost: $5–$15 for the belt. One of the cheapest washer repairs.

4. Motor Coupling Failure (Direct-Drive Models)

Some Maytag direct-drive washers use a motor coupling — a plastic and rubber connector between the motor shaft and the transmission input. It's designed to break (as a safety measure) before the motor or transmission is damaged by an overload.

Symptoms:

• Motor runs but the drum doesn't move at all (no agitation or spin)
• No unusual noises — the motor sounds normal but nothing happens

How to check:

1. Unplug the washer and remove the cabinet.
2. The motor coupling is located between the motor and the gearcase/transmission.
3. If the coupling is broken, you'll see pieces of the plastic drive forks or the rubber isolator will be torn.

Part number: WP285753A — universal for most Maytag/Whirlpool direct-drive washers.

Cost: $8–$15 for the part. Replacement takes about 30–45 minutes.

5. Clutch Assembly Wear

The clutch assembly (on models equipped with one) engages the spin basket gradually to bring it up to speed. Over time, the clutch pads wear down — similar to a car's clutch.

Symptoms:

• Slow or weak spin speed
• Spin speed gradually decreases over months
• Burning smell during the spin cycle
• Clothes come out wetter than usual
• Shavings or black dust under the washer

Part number: WP285785 for most Maytag/Whirlpool top-load models.

Cost: $40–$60 for the part. This is a more involved repair as it requires removing the spin basket and transmission — professional installation is recommended ($200–$350 total).

6. Failed Motor Control Board or Main Board

Newer Maytag washers with electronic controls use a motor control board (located at the bottom of the machine) and a main control board (in the console). Either can fail and prevent proper spin operation.

Symptoms:

• Error codes on the display (F7 E1 = shift actuator/motor, F7 E5 = motor control)
• The washer starts a spin cycle but immediately stops
• Motor runs in one direction but not the other
• Complete failure to start any cycle

How to diagnose:

1. Run the diagnostic test mode (described in section 2).
2. Note any error codes displayed during the test.
3. Check the motor control board (bottom of machine) for visible damage — burned components, melted connectors, or corrosion.

Cost: Motor control board (W10756692) runs $80–$150. Main control board (W10480169) runs $100–$200. Professional diagnosis and installation adds $100–$200.

7. Drain Pump Failure or Clog

A Maytag washer won't spin if it can't drain the water first. The drain pump must successfully evacuate the tub before the spin cycle can begin.

Symptoms:

• Water remains in the tub at the end of the cycle
• You hear a humming sound from the pump area during drain time
• Error code F5 E2 (door/lid lock related to drain) or F9 E1 (long drain)

How to fix:

1. Unplug the washer.
2. Locate the drain pump at the bottom of the machine.
3. Check the pump filter/trap (if equipped) for coins, buttons, hair ties, or other debris.
4. Inspect the drain hose for kinks or blockage.
5. Test the pump motor for continuity.
6. If the pump impeller is broken or the motor is burned out, replace the pump assembly.

Part number: WPW10730972 (drain pump for most Maytag models), $20–$40.

Maytag Washer Diagnostic Mode

For Maytag Centennial and Bravos models:

1. Start with the washer in standby mode (plugged in, all lights off).
2. Within 12 seconds, rotate the cycle knob: counterclockwise one click, clockwise three clicks, counterclockwise one click, clockwise one click.
3. All indicator lights should illuminate, then the washer enters test mode.
4. Press Start to begin automatic testing. The washer will cycle through each function.
5. Error codes display during or after the test.

For Maytag Maxima front-load models:

1. Press and hold the Drain/Spin + Options buttons for 3 seconds.
2. The display enters diagnostic mode.

Preventive Maintenance for Maytag Washers

• Don't overload — Maytag top-loaders should be filled to about 3/4 capacity. Overloading stresses the motor coupling, clutch, and shift actuator.
• Level the washer — An unlevel washer causes excessive vibration during spin, wearing out suspension components and bearings.
• Clean the drain pump filter monthly (if accessible on your model).
• Use HE detergent in HE models — excessive suds reduce spin efficiency and can trick the pressure sensor.
• Run a Clean Washer cycle monthly with affresh tablets or a cup of white vinegar.

Frequently Asked Questions

Q: Why does my Maytag washer hum but not spin? A: A humming sound without spinning usually indicates the motor is receiving power but the drive mechanism is failing. On belt-driven models, the belt may be broken or slipping. On direct-drive models, the shift actuator may have failed, preventing the transition from agitate to spin mode. A failed motor coupling will also produce this symptom.

Q: What does the F7 E1 error code mean on a Maytag washer? A: F7 E1 indicates a motor speed sensing error — the motor isn't reaching the expected RPM during the spin cycle. This is most commonly caused by a failed shift actuator (W10913953), though it can also indicate a worn drive belt, overloaded tub, or failing motor.

Q: How do I manually drain a Maytag washer that won't spin? A: If the washer won't drain, pull the drain hose from the standpipe and lower it into a bucket below the washer's level. Gravity will drain the water. Alternatively, on some Maytag models, there's an emergency drain hose behind a small access panel at the bottom-front of the machine. Pull it out, open the cap, and drain into a shallow pan.

Q: Is it worth repairing a Maytag washer that's 10 years old? A: Maytag washers are built for longevity, especially the Commercial Technology line. At 10 years, most repairs ($150–$350) are still cost-effective compared to buying a new washer ($700–$1,200). The exception would be a failed transmission or tub bearing, which can cost $400–$600 for professional repair.

Q: Why does my Maytag washer shake violently during spin? A: Violent shaking is usually caused by an unbalanced load, worn shock absorbers/suspension rods, or an unlevel washer. On front-loaders, the shipping bolts may still be installed (they must be removed before first use). Check that the washer is level with a bubble level and adjust the leveling legs accordingly.

When to Call a Professional

Certain Maytag washer repairs benefit from professional service:

• Transmission or gearcase replacement — This is the most complex and expensive washer repair, requiring removal of the entire drive system. If the transmission has failed, a professional can determine whether repair or replacement of the washer is more economical.
• Tub bearing replacement — A loud grinding noise during spin indicates bearing failure. This repair involves splitting the outer tub (on some models) and is a 2–3 hour job even for experienced technicians.
• Electronic control board diagnosis — Multiple error codes or intermittent electrical issues require systematic diagnostic skills and sometimes access to Maytag's service manuals.
• Spin basket removal — Some repairs (clutch, bearing) require removing the spin basket, which may be seized due to corrosion and requires special tools to remove without damage.

Professional repair eliminates guesswork, prevents damage from inexperience, and comes with a repair warranty that DIY work doesn't offer.
